Typ: A Round jet

• Op pressure: max. 2000 bar
• Effic. factor: 0,95
• Material: Steel
• Nozzle Ø: 0.4 - 4.9 mm
• Form : 8/12 x 24 long

Typ: B Fan jet

• Op pressure: max. 2000 bar
• Effic. factor: 0,67
• Material: Steel
• Nozzle Ø: 0.8 - 3.0 mm
• Form : 8/12 x 24 long

Typ: C Round jet

• Op pressure: max. 400 bar
• Effic. factor: 0,92
• Material: Steel
• Nozzle Ø: 0.4 - 4.6 mm
• Form: G1/4" x 12 lonh

Typ: D Fan jet

• Op pressure: max. 400 bar
• Effic. factor: 0,67
• Material: Steel
• Nozzle Ø: 0.4 - 4.6 mm
• Form: G1/4 " x 12 long

Typ: E Round jet

• Op pressure: max.2500 bar
• Effic. factor: 0,92
• Material: Steel
• Nozzle Ø: 0.25 - 1.2 mm
• Form Ø: 4.5/3.25 x 4 long

Typ: F Round jet

• Op pressure: max. 2500 bar
• Effic. factor: 0,63
• Material: Steel/sapphire
• Nozzle Ø: 0.10 - 0.8 mm
• Form Ø: 9.5/3.2 x 6 long

Typ: G Round jet

• Op pressure: max. 2500 bar
• Effic. factor: 0,92
• Material: Steel
• Nozzle Ø: 0.25 - 1.2 mm
• Form Ø: M12 x 12 long

Typ: H Round jet

• Op pressure: max. 2500 bar
• Effic. factor: 0,75
• Material: Steel/sapphire
• Nozzle Ø: 0.25 - 1.0 mm
• Form Ø: M12 x 17 long

Typ: I Round jet

• Op pressure: max. 3000 bar
• Effic. factor: 0,7
• Material: Steel/sapphire
• Nozzle Ø: 0.4 - 1.1 mm
• Form Ø: 8/12 x 17 long

Typ: K Round jet

• Op pressure: max. 2500 bar
• Effic. factor: 0,75
• Material: Steel/sapphire
• Nozzle Ø: 0.3 - 1.0 mm
• Form Ø: 8/12 x 14.5 long

Typ: L Round jet

• Op pressure: max. 1200 bar
• Effic. factor: 0,95
• Material: Steel
• Nozzle Ø: 1.0 - 3.9 mm
• Form Ø: 12.5/16.8 x 27 long

Typ: M Round jet

• Op pressure: max. 2500 bar
• Effic. factor: 0,95
• Material: Steel/ceramic
• Nozzle Ø: 1,0 - 3,9 mm
• Form Ø: 12.5/16.8 x 27 long

Typ: N Round jet

• Op pressure: max. 2500 bar
• Effic. factor: 0,63
• Material: Steel/sapphire
• Nozzle Ø: 0.2 - 1.0 mm
• Form Ø: M4 x 4 long

Typ: O Round jet

• Op pressure: max. 2500 bar
• Effic. factor: 0,63
• Material: Steel/sapphire
• Nozzle Ø: 0.3 - 1.05 mm
• Form Ø: M6 x 0.75 x 6 long

Typ: P Round jet

• Op pressure: max.3000 bar
• Effic. factor: 0,71
• Material: Steel/sapphire
• Nozzle Ø: 0.15 - 1.5 mm
• Form Ø: M10 x 19 long

Typ: R Fan jet

• Op pressure: max. 3000 bar
• Effic. factor: 0,67
• Material: Steel
• Nozzle Ø: 0.3 - 1.2 mm
• Form Ø: 7/10 x 13 long

Typ: S Round jet

• Op pressure: max. 3000 bar
• Effic. factor: 0,95
• Material: Steel
• Nozzle Ø: 1.0 - 1.8 mm
• Form Ø: M4 x 5.2 long

Typ: T Round jet

• Op pressure: max. 3500 bar
• Effic. factor: 0.72 - 0.92
• Material: Steel/diamond
• Nozzle Ø: 0,.5 - 1.00 mm
• Form Ø: M10 x 19.5 long

Typ: U Round jet

• Op pressure: max. 4000 bar
• Effic. factor: 0,7
• Material: Steel/sapphire
• Nozzle Ø: 0.2 - 1.0 mm
• Form Ø: 3.15/7 x 13 long
